Is Smart Device : no
Power Supply : Solar cells, CR2450 lithium battery
Sensitivity : 1/25000s
Cartridge Size : 114x133x10mm
Solar Powered : YES
View Area : 100x97mm
Switch Time : 0.2-1.0s adjustable
Auto-Darkening : YES
Model Number : UN109
Material : PP
Certification : CE
Type : Welding Mask Professional
Optical Clarity : 1/1/1/1
Light state : DIN.4
Dark state : DIN.5-8/9-13
Power on/off : Fully automatic
Shade knob : Out
Protect Grade against UVB : DIN 16
Operating Temperature : - 5℃-+ 55℃
Arc sensor : 4 pieces
With cutting function : Yes
Self-test function : Yes
Low battery alert : Yes
UN109 Specification:
Type: Welding Helmet
Optical Clarity:1/1/1/1
Filter size: 114×133×10mm
Viewing Area: 100×97mm
Light state: DIN.4
Dark state: DIN.5-8/9-13
Switch time: 1/25000s
Delay time: 0.2-0.8s adjustable
Power supply: Solar cells, CR2450 lithium batteries
Power on/off: Fully automatic
Shade knob: Out
Arc sensor: 4
Suitable for ARC, MIG, Spot, Micro, Wire, AC, DC, and Plasma Welders and Plasma Cutters.
UN106 Specification:
Optical Clarity:1/1/1/2
Viewing area (mm): 100*60
Size of the cartridge (mm): 114*133*10
UV / IR Protection: DIN16
Light / Dark state: DIN4/5-9/9-13
Arc Sensors: 4
Power Supply: Solar cells+Replaceable CR2032 lithium battery
Replace Battery: YES
Switching time: 1/30000s
Delay time (dark to light): 0.1-1.0S Variable adjusted by an internal knob
Low TlG amps rated: 5 amps (DC/AC)
Grinding: YES
Features:*Large Viewing Screen & True Color:
The auto darkening welding helmet provides large viewing screen 3.94"X3.81" with 4 Premium Sensors and adopts the latest True-Color technology to restore every detail of working conditions.
*1/1/1/1 optical clarity:
This welding helmets features is improving visibility and reduces eye strain by minimizing the traditional lime green color in the view screen.
*Ultimate eye protection:
The SAFEUP welding helmet auto-darkening function goes from light to dark in 1/25,000 seconds; high-quality liquid crystals and optical coatings protect against UV and infrared radiation as well as glare, in accordance with DIN5-9/9-13 protection standards.
*4 Arc Sensors:
The SAFEUP welding mask includes 4 intelligent arc sensors that adapt to different environments and task durations; whether for grinding or welding applications, the welding mask is ideally suited for MIG, MAG, MMA and ARC welding processes.
Package Included:
1x Welding Helmet(with battery)
1x Headband
1x Manual
